7.6 Speed Change during Movement
Example of use in operation) The actuator speed is reduced at a certain point during movement.
The position 150 mm from the home is set as position 1, and the position 200 mm
from the home is set as position 2. The actuator is initially located between the
home and position 1. The actuator is moved to position 2 being the target position,
at a travel speed of 200 mm/sec to position 1 and that of 100 mm/sec from
position 1 to position 2.
Method) In this example, the actuator is caused to move to position 1 and to position 2
successively. Before the actuator is stopped at position 1, command position 2
must be selected/entered and the start signal must be input. To do this, set a wide
positioning band at position 1 and cause the start signal for movement to position
2 to be input immediately after the completion signal for movement to position 1 is
output. (Command position 2 should be entered while the actuator is moving to
position 1.)
ERC controller
P
L
C
[9] [7] [4] [2]
[1]
[5]
Signal name
Start
Command position 1
Command position 2
Command position 4
*Pause
Position complete
Home return completion
Zone
*Alarm
PIO
Category
Input
Output
Reference flow
Select/enter command position 1.
Start input ON
Movement to position 1 starts at 200 mm/sec.
Position complete output OFF
Start input OFF
Select/enter command position 2.
Start input ON
Position complete output OFF
Start input OFF
Movement to position 2 completes.
Position complete output turns
ON 10 mm before position 1.
Movement to position 2 starts at 100 mm/sec.
Position complete output turns
ON 0.1 mm before position 2.
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[10] [8] [6] [3]
