110
9. Troubleshooting
9.1 Action to Be Taken upon Occurrence of Problem
Upon occurrence of a problem, take appropriate action according to the procedure below in order to ensure
speedy recovery and prevent recurrence of the problem.
a) Check the status indicator lamps.
Illuminating in green --- The servo is ON.
Illuminating in red ---
An alarm is present or the motor drive power is cut off.
b) Check for error in the host controller.
c) Check the voltage of the main 24-VDC power supply.
d) Check for alarm.
Confirm the details of error on the PC or teaching pendant.
e) Check the cables for connection error, disconnection or pinching.
Before performing a continuity check, turn off the power (to prevent a runaway actuator) and disconnect the
cables (to prevent accidental power connection due to a sneak current path).
f) Check the I/O signals.
g) Check the noise elimination measures (grounding, installation of surge killer, etc.).
h) Review the events leading to the occurrence of problem, as well as the operating condition at the time of
occurrence.
i) Check the serial numbers of the actuator.
j) Analyze the cause.
k) Take
action.
Please check items a) through i) before contacting IAI.
9.2 Alarm Level Classification
Alarms are classified into three levels according to the symptoms they represent.
Alarm level LED color *ALM signal
What happens when alarm
generates
How to reset
Message Green Not output An error is displayed on the PC or teaching pendant.
Operation
cancellation
Red Output
The actuator decelerates to a stop
and then the servo turns OFF. Reset the alarm on the
PC/teaching pendant.
Cold start Red Output
The actuator decelerates to a stop
and then the servo turns OFF.
Reconnect the power.
(Note) Reset each alarm after identifying and removing the cause. If the cause of the alarm cannot be removed
or when the alarm cannot be reset after removing the cause, please contact IAI.
If the same error occurs again after resetting the alarm, it means the cause of the alarm has not been
removed.
