86

H-Class

Advanced Entry Calibration (continued)

Step

Action

Displayed Message

Comment

J

Use the buttons to

increment the Gain
Number by one and then

press ENTER. Record the
TOF Value. Repeat this

process for each Gain
Number.

TRAN SENSOR GAIN


yyy (0 - 31)

01

These are TOF Values,

where “yyy” represents
the current sensor

reading.

Sample Calibration Table

Gain Number

Label Value

TOF Value

Difference Value

00 252 248

01 250 245

02 248 234

… … …

31 09 14


Step

Action

Displayed Message

Comment

K

In your sample calibration

table, where both the
Label Value and TOF Value

are at least 20, subtract
the amounts and record

the result as a Difference
Value (see below).


Identify the largest
Difference Value and the

corresponding Gain
Number. This Gain

Number will be used to
resample the media.

TRAN SENSOR GAIN


yyy (0 - 31)

31

In this example, Gain

Number 18 is chosen
because, where both

values are at least
twenty, it has the highest

Difference Value.

Sample Calibration Table

Gain Number

Label Value

TOF Value

Difference Value

00 252 248 4

01 250 245 5

02 248 234 14

… … … …

15 188 63 125

16 184 51 133

17 179 38 141

18

174

25

149

19 170 19 N/A

… … … …

31 132 14 N/A
