H-Class

83

Advanced Entry Calibration

Step

Action

Displayed Message

Comment

A

Turn ON the printer.

CANNOT CALIBRATE

-or-

UNCALIBRATED

Wait briefly for

initialization to complete;
see Section 4.1.1.

B

Press ENTER to access
MEDIA SETTINGS. Then

using the UP Button, scroll
to SENSOR CALIBRATION.

MEDIA SETTINGS

ADVANCED MENU must
be enabled to access the

calibration selections.

C

Press ENTER to access

SENSOR CALIBRATION.
Using the DOWN Button,

highlight ADVANCED
ENTRY then press ENTER.

ADVANCED ENTRY

Press EXIT to abort this

procedure.

D

Scroll to TRAN SENSOR
GAIN (or REFL SENSOR

GAIN, if using reflective
media) then press ENTER.

TRAN SENSOR GAIN

yyy (0 - 31)
25

The following examples
detail die-cut media

calibration; however,
unless otherwise noted,

the reflective media
procedure is the same.

E

Install media. Position the

Media Sensor under the
label, then lower and latch

the Printhead Assembly.

TRAN SENSOR GAIN


yyy (0 - 31)

25

See Section 3.2 for

sensor adjustment
instructions.

Do not position the
Media Sensor under a
perforation; and if

using preprinted
media, ensure the

label area placed over
the sensor is free of
text, graphics, lines,
etc.
