H-Class 49
Printer Options (continued)
Menu Item Details
END OF PRINT
Sets the type of output signal generated to indicate
EOP, where:
LOW PULSE
Outputs a low pulse upon completion.
HIGH PULSE
Outputs a high pulse upon completion.
ACTIVE LOW
Outputs a logic low upon completion.
ACTIVE HIGH
Outputs a logic high upon completion.
RIBBON LOW
Sets the low ribbon signal (as determined by RIBBON
LOW OPTIONS; see Section 4.2.1), where:
ACTIVE LOW
Outputs a logic low when the roll size reaches the
setting.
ACTIVE HIGH
Outputs a logic high when the roll size reaches the
setting.
SLEW ENABLE
Selects the type of input signal required to initiate
label slew, where:
STANDARD
Triggers slew with a low signal.
LOW PULSE
Triggers slew with a low pulse.
HIGH PULSE
Triggers slew with a high pulse.
ACTIVE LOW
Triggers slew with a low signal.
ACTIVE HIGH
Triggers slew with a high signal.
BACKUP LABEL
Determines reverse label motion when the GPIO option
is installed and enabled, where:
DISABLED
Disables backup.
ACTIVE LOW Triggers backup with a low signal.
ACTIVE HIGH
Triggers backup with a high signal.
