80

H-Class

5.2 Calibration

Calibration ensures correct media detection. Use Standard Calibration if the quick method

(see Section 3.4) fails.


5.2.1 Standard

Calibration

Standard Calibration provides dynamic readings, which can be helpful when using media

with small position-critical notches or marks. Three calibration samples are required:

Empty – with nothing over the sensor;

Gap (or Mark) – with media liner, a notch, or a mark over the sensor; and,

Paper – with the label (and liner, if any) over the sensor.

Calibrate the Media Sensor using the steps below:

Before proceeding, ensure that the ADVANCED MENU is enabled (see Section

4.2.4) and that the SENSOR TYPE is selected (see Section 4.2.1).

Step

Action

Displayed Message

Comment

A

Turn ON the printer.

CANNOT CALIBRATE

-or-

UNCALIBRATED

Wait briefly for

initialization to complete;
see Section 4.1.1.

B

Press ENTER to access
MEDIA SETTINGS. Then

using the UP Button, scroll
to SENSOR CALIBRATION.

MEDIA SETTINGS

ADVANCED MENU must
be enabled to access the

calibration selections.

C

Press ENTER to access

SENSOR CALIBRATION.
Press ENTER again to
select PERFORM

CALIBRATION and then
press YES to proceed.

PERFORM CALIBRATION

Press NO to abort this

procedure.

D

With no media installed,
press ESC.

REMOVE LABEL STOCK

PRESS ESC KEY

yyy

This sets the empty
value, where “yyy”

represents the current
sensor reading.
