3 ribbon loading – Datamax-O'Neil H-Class Operator’s Manual User Manual
Page 36
26
H-Class
C. Lower the Printhead Assembly then rotate the Printhead Latch completely clockwise.
D.
If necessary, return to Media Loading to complete the setup process; otherwise,
close the cover. With READY displayed, press and hold the FEED Key until at least
one gap (or mark) advances; see Section 3.4.
If using REFLECTIVE or CONTINUOUS media, select the appropriate SENSOR TYPE;
see Section 4.2.1.
3.3 Ribbon Loading
Ribbon, required when printing on thermal transfer media, should be loaded as follows:
The use of ribbon slightly wider than the media (and liner, if any) is recommended
to help protect against abrasive wear.
A. Rotate the Printhead Latch counterclockwise then raise the Printhead Assembly.
