H-Class

Media (continued)

H-6210 & H-6308 Media Dimensional Requirements

[1]

Minimum

Maximum

Designator

Description

inches

mm

inches

mm

A Label

width

2.00 51 6.7 170

B Liner

width

2.00 51 6.7 170

C

Gap (or notch) between labels

[3]

.08 2

– –

D Label

length

[3]

.25

6

E Media

thickness

.0025

.06 .01 .25

F Notch

opening

width

.08 2 – –

G

Media edge to sensor aperture

.20

5

2.25

70

H Reflective

mark

width

[2]

.47

12

6.7

170

I

Distance between reflective marks

[3]

.25 6

– –

J Reflective

mark

length

[3]

.08

2

K

Label repeat distance

[3]

.33

8

[1]

Units of measure are referenced by the direction of label feed.

[2]

The reflective (black) mark must be carbon based, placed on the backside of the stock, and the

reflectance shall be less than 10% at wavelengths of 950 and 640 nm.

[3]

The maximum allowable length of the combined label and gap (or mark) measurement cannot

exceed 99.99 inches.




H-6212X & H-6310X Models

Mechanical

Height:

16.4 inches (415.3 mm)

Width:

15 inches (381 mm)

Depth:

19.3 inches (489 mm)

Weight:

53 pounds (24 kg)


Electrical

Display:

Graphics (240 X 320 pixels) with backlight.
