62

H-Class

Communications (continued)

Menu Item

Details

SERIAL PORT C

Controls the settings for the optional Applicator
Interface COM C (J4) port, where the settings are the

same as those given for the SERIAL PORT A.

The maximum baud is 38.4K BPS.

SERIAL PORT D

Controls the settings for the optional Applicator
Interface COM D (J3) port, where the settings are the

same as those given for the SERIAL PORT A.

The maximum baud is 38.4K BPS.

PARALLEL PORT A

Controls the communications settings for Parallel Port
A, where:

PORT DIRECTION

Allows printer data to be returned to the host, where:

UNI-DIRECTIONAL

Returns no data (one-way communication).

BI-DIRECTIONAL

Returns data (compliant back-channel operation); see

Section 2.2.2 for cable requirements.

NIC ADAPTER

Controls the communications settings for the network

interface, where:

QUICK SETUP

Selects settings to configure basic Wired or WiFi

operations, where:

WIRED DHCP

Selects Wired operation, where:

NO

Exits the menu item without changing the current

settings.

YES

Returns the NIC Adapter to defaults then sets Wired

Discovery to “Enable” and Wireless to “Disable.”
