MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide

PRELIMINAR

Y

Command/Response Table for IP SIS Commands

Symbol definitions

X3)

= Matrix name

(Up to 240 alphanumeric characters)

N

The following characters are invalid in the name: {space} ~ , @ = ` [ ] { } < > ‘ “ ; : | \ and ?.

X3!

= Default name

CP-300-450-MAV--

+ last 3 pairs of MAC address

X3@

= Time and date (for set)

In the format: MM/DD/YY•HH:MM:SS where:

MM = month: 01 (January) through 12 (December)

DD = 01 through 31

YY = 00 through 99

HH = 00 through 24

MM = 00 through 59

SS = 00 through 59

X3#

= Time and date (for read)

In the format: Day,•DD•Mmm•YYYY•HH:MM:SS where:

Day = weekday: Mon through Sun

DD = 01 through 31

Mmm = month: Jan through Dec

YYYY = 2000 through 2099

HH = 00 through 24

MM = 00 through 59

SS = 00 through 59

X3$

= GMT offset

–12.0 through +14.0. Hours and minutes removed from GMT

X3%

= Daylight Savings Time

0 = Daylight Savings Time off/ignore

1 = Daylight Savings Time on (northern hemisphere)

2 = Daylight Savings Time on (Europe)

3 = Daylight Savings Time on (Brazil)

X3^

= IP address

###.###.###.###

X3&

= Hardware (MAC) address

##-##-##-##-##-##

X3*

= Number of open connections

0 - 255

X3(

= Password

12 alphanumeric characters

N

The following characters are invalid in passwords: {space} + ~ , @ = ` [ ] { } < > ‘ “ ; : | \ and ?.

X4)

= Domain name

Standard domain name rules apply (for example: [email protected])

N

The following characters are invalid in a domain name: {space} + ~ , = ` [ ] { } < > ‘ “ ; : | \ and ?. The @ character is acceptable only as

the lead-in to the domain name (such as @extron.com).

X4!

= E-mail account

65 - 72. 65 = e-mail recipient 1, 66 = 2, 67 = 3, ... 72 = recipient #8

X4@

= E-mail address

Typical e-mail address format (for example: [email protected])

X4#

= Notify when?

0 = no response

2 = fixed/restored

1 = fail/missing

3 = both 1 & 2

X4$

= Notification selections

01 through 16 = input 1 through input 16

17 = power supply

X4%

= Notify status (for read)

17-digit number. For each digit: 0 = do not notify, 1 = notify

X4^

= DHCP

0 =1 off, 1 = on

X4&

= Port #

00 through 99 (00 = all ports)

X4*

= Baud rate

9600, 19200, 38400, 115200

X4(

= Parity

o

dd, even, none, mark, space (Only the first letter required.)

X5)

= Data bits

7, 8

X5!

= Stop bits

1, 2

X5@

= Port type

0 = RS-232

1 = RS-422

2 = RS-485

X5#

= Verbose mode

0 = clear/none (default for Telnet connection)

1 = verbose mode (default for RS-232/RS-422 connection)

2 = tagged responses for queries

3 = verbose mode and tagged for queries

N

If tagged responses is enabled, all read commands return the constant string and the value as the set command does

(for example, the read matrix name command

E

CN

}

, returns Ipn•

X3)]

).

X5$

= RAM status

0 = RAM dirty (needs saving to flash memory)

1 = RAM has been saved (ok to power off/reset)
