Ethernet Connection, cont’d

MVX Plus 128 VGA A Matrix Switcher • Ethernet Connection

A-4

PRELIMINAR

Y

Connecting as a Telnet client

The Microsoft Telnet utility is available from the DOS prompt. Telnet allows you

to input SIS commands to the MVX Plus 128 VGA A switcher from the PC via the

Ethernet link and the LAN.
Access the DOS prompt and start Telnet as follows:

1

.

On the Windows task bar, click on Start > Run.

2

.

At the Open prompt, type command.

3

.

Click the OK button.

4

.

At the DOS prompt, type telnet and then press [Enter]. The computer returns

a display similar to figure A-3.

Microsoft (R) windows 2000 (TM) Version 5.0 (Build 2195)
Welcome to Microsoft Telnet Client
Telnet Client Build 5.00.99203.1

Escape Character is 'CTRL+]'

Microsoft Telnet>

Figure A-3 — Telnet screen

Telnet tips

It is not the intention of this manual to detail all of the operations and functionality

of Telnet; however, some basic level of understanding is necessary for operating the

MVX Plus 128 VGA A switcher via Telnet.

Open

Connect to the MVX Plus 128 VGA A switcher using the Open command. Once

you are connected to the switcher, you can enter the SIS commands the same as you

would if you were using the RS-232 link.
Connect to the MVX Plus 128 VGA A switcher as follows:

1

.

At the Telnet prompt, type open {IP address} and then press [Enter].

If the switcher is not password protected

, no further prompts are displayed

until you break or disconnect the connection to the MVX Plus 128 VGA A

switcher.

If the switcher is password protected

, Telnet displays the password prompt.

2

.

If necessary, at the password prompt, type {password} and then press [Enter].

Connection to the switcher via the Ethernet can be password protected. There

are two levels of password protection: administrator and user. A person

logged on as an administrator has full access to all MVX Plus 128 VGA A

switching capabilities and editing functions. Users can select video and/or

audio for output, select test patterns, set RGB and audio mutes, select a blue

screen, and view all settings with the exception of passwords. By default, the

MVX Plus 128 VGA A switcher ships with both passwords set to {carriage

return}.
