MVX Plus 128 VGA A Matrix Switcher • Quick Start
QS-2
PRELIMINAR
Y
Quick Start —
MVX Plus 128 VGA A Matrix Switcher, continued
Esc button
cancels selections in progress and
resets the front panel button indications.
The Esc button does not reset the current
configuration, the RGBHV and audio
selection, any presets, or any audio level
or volume settings. On audio models,
Esc increments the level and volume. See
“Viewing and adjusting the audio level” in
the next column.
RGBHV and Audio buttons
select/deselect
video and/or audio. The Audio button blinks
to indicate audio breakaway. The Audio
button also selects the audio level/adjust
mode. See “Viewing and adjusting the audio
level” in the next column.
Creating a tie
1
. Press and release the RGBHV and/or Audio
I/O button(s) to select or deselect video and/
or audio as desired.
2
. Press and release the desired input button.
3
. Press and release the desired output button(s).
4
. Press and release the Enter button.
I / O
RGBHV AUDIO
Green when selected.
Off when deselected.
Red when selected.
Off when deselected.
5
The button lights to indicate the selection.
3 4
ENTER
8
Amber indicates RGBHV/video and audio tie.
Green indicates RGBHV/video only tie.
Red indicates audio only tie.
Green indicates the need
to confirm the change.
PRESET
PRESET
PRESET
PRESET
Preset button blinks.
Press and
hold.
2 seconds
Save a
preset
Recall a
preset
Preset button lights.
Press and release.
All input and output buttons with
assigned presets light
red.
The configuration data at assigned
preset locations will be overwritten.
INPUTS
1 2 3 4 5 6 7
1
ENTER
The button blinks
red to indicate that
this
preset is selected to save or recall.
The Enter button blinks
green to indicate the need
to activate the save or recall.
AUDIO
AUDIO
Audio button blinks.
Press and
hold
2 seconds
1
2
5
Press an
Input button to adjust gain/attenuation.
Press an
Output button to adjust volume.
Output buttons display gain/attenuation.
Input buttons display volume.
ESC
VIEW
button decreases
the level or volume.
button increases
the level or volume.
Saving or recalling a preset
1
. Save a preset — Press and hold the Preset
button for 2 seconds.
Recall
a preset — Press and release the Preset
button.
2
. Press and release the desired input or output
button.
3
. Press and release the Enter button.
Viewing and adjusting the audio level
1
. Press and hold the Audio button.
2
. Press an input or output button. See chapter 3,
“Operation” to read the displayed value.
3
. Increase and decrease the gain/attenuation
or volume level by pressing the Esc (
>
) and
View (
<
) buttons.
4
. Press and release the Audio button to exit.
