MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide

PRELIMINAR

Y

Command/response table for SIS commands (continued)

Command

ASCII command

(host to switcher)

Response

(switcher to host)

Additional

description

View ties, gain, volume, mutes, presets, and DSVP (continued)

View video global preset
configuration

EX1!

*1*1VC

}

X@

1

•X@

2

...

•X@

16

Vid

]

Show preset

X1!

’s video

configuration. Show the
input tied to 16 sequential
outputs, starting from
output 1.

Command description:
Response description:

preset #*starting output # (O# - should always be 1)*1(=video)VC
input # (I#) tied to O#1•I# tied to O#2•I# tied to O#3• ... •I# tied to O#16•Vid

]

Example:

1

Output:

Response = tied input:

input 12 tied to output 3

2

3

4

5

6

7

8

08•08•12•08•08•11•00•00

no tied input

input 8 tied to output 4

•--•--•--•--•--•--•--•--•

13 14 15 16

09 10 11 12

outputs do not exist

•Vid

Each position shown in the response is an output: left = output 1, right = output 16.
(Outputs 9 through 16 are not present on the MVX Plus 128 VGA A.) The number in each
position is the input tied to that output.
In this example, video input 8 is tied to outputs 1, 2, 4, and 5; input 12 is tied to output 3;
and input 11 is tied to output 6. No inputs are tied to outputs 7 and 8.

N

EX1!

*1*1VC

}

where

X1!

= 0 returns the switcher’s current video configuration.

View audio global preset
configuration

EX1!

*1*2VC

}

X@

1

X@

2

•...•

X@

16

•Aud

]

Show preset

X1!

’s audio

configuration. Show the
input tied to 16 sequential
outputs, starting from
output 1.

Command description:
Response description:

preset #*starting output # (O# - should always be 1)*2(=audio)VC
input # (I#) tied to O#1•I# tied to O#2•I# tied to O#3• ... •I# tied to O#16•Aud

]

Example:

01

Output:

Response = tied input:

input 1 tied to output 3

02 03 04 05 06 07 08

01•01•01•01•02•12•12•00•--•--•--•--•--•--•--•--•Aud

13 14 15 16

09 10 11 12

no tied input outputs do not exist

Each position shown in the response is an output: left = output 1, right = output 16.
(Outputs 9 through 16 are not present on the MVX Plus 128 VGA A.) The number in each
position is the input tied to that output.
In this example, audio input 1 is tied to outputs 1, 2, 3, and 4; input 2 is tied to output 5;
and input 12 is tied to outputs 6 and 7. No input is tied to output 8.

N

EX1!

*1*2VC

}

where

X1!

= 0 returns the switcher’s current audio configuration.

View video room preset
configuration

EX*

*

X1@

*1*1VC

}

X@

1

•X@

2

...

•X@

16

Vid

]

Show room

X*

, preset

X1!

’s

video configuration. Show
the input tied to up to 16
outputs assigned to room

X*

.

Command description:
Response description:

room #*room preset #*starting output # (O# - should always be 1)*1(=video)VC
input # (I#) tied to O#1

I# tied to O#2

I# tied to O#3

...

I# tied to O#12

Vid

]

View audio room preset
configuration

EX*

*

X1@

*1*2VC

}

X@

1

•X@

2

...

•X@

16

Aud

]

Show room

X*

, preset

X1!

’s

audio configuration. Show
the input tied to up to 16
outputs assigned to room

X*

.

Command description:
Response description:

room #*room preset #*starting output # (O# - should always be 1)*2(=audio)VC
input # (I#) tied to O#1

I# tied to O#2

I# tied to O#3

...

I# tied to O#12

Aud

]
