Operation, cont’d

MVX Plus 128 VGA A Matrix Switcher • Operation

3-26

PRELIMINAR

Y

Using presets

The current configuration (configuration 0) can be saved as a preset in any one of

32 preset memory addresses. Preset locations are assigned to the input buttons and

output buttons. Up to 20 presets can be selected from the front panel to be either

saved or retrieved. When a preset is retrieved from memory, it becomes the current

configuration

.

N

• Only the audio and video ties are stored and recalled; audio gain settings are

not saved, and they do not change when a preset is recalled.

• Presets cannot be viewed from the front panel unless recalled as the current

configuration. Presets can be viewed using Extron’s Windows-based control
program. See chapter 5, “Matrix Software”, for more details.

• The current configuration and all presets are stored in non-volatile memory.

When power is removed and restored, the current configuration is still active
and all presets are retained.

• When a preset is recalled, it replaces the current configuration, which is lost

unless it is also stored as a preset. The recalled preset overwrites all of the
current configuration ties in favor of the preset configuration ties.

• Preset numbers that are too high to be available from the front panel are still

accessible under RS-232/RS-422 or Ethernet control.

• Figure 3-39 shows the presets associated with the various input and output

buttons for the MVX Plus 128 VGA A.

Input
buttons

Output
buttons

Preset

1

Preset

5

Preset

10

Preset

2

Preset

11

Preset

3

Preset

8

Preset

12

Preset

6

Preset

7

Preset

4

Preset

13

Preset

17

Preset

14

Preset

15

Preset

20

NOTE

Presets 21 through 32 are available via

RS-232/RS-422 and Ethernet control only.

Preset

18

Preset

19

Preset

16

Preset

9

INPUTS

1 2 3 4 5 6 7 8 9 10 11 12

1 2 3 4 5 6 7 8

OUTPUTS

Figure 3-39 — Preset locations
