5-5 MVX Plus 128 VGA A Matrix Switcher • Matrix Software
PRELIMINAR
Y
If the address is not correct: Either click in the Extron IP Address field
and enter the IP address or click on the scroll down button ( ) and select
from among the recently used addresses. Proceed to step 3b.
N If the local system administrators have not changed the value, the factory-
specified default, 192.168.254.254, is the correct value for this field.
b . If the switcher is password protected, click in the Password field and
enter the enter the appropriate administrator or user password.
c . Click Connect.
If you logged on using the administrator password, the Windows
program connects you to the MVX Plus 128 VGA A switcher with all of
the administrator rights and privileges.
If you logged on using the user password, the Windows program
connects you to the MVX Plus 128 VGA A switcher with only user
capabilities.
If an incorrect password was entered, the program beeps and returns to
the password entry display.
4 . The Extron Matrix Switchers Control Program window (figure 5-5 and
figure 5-6) appears. The window displays the current configuration of the
attached matrix.
Figure 5-5 — Extron Matrix Switchers Control Program window (no ties)
