3-41

MVX Plus 128 VGA A Matrix Switcher • Operation

PRELIMINAR

Y

Setting the front panel locks (Executive modes)

The matrix switcher has three levels of front panel security lock that limit the

operation of the switcher from the front panel. The three levels are:

Lock mode 0 — The front panel is completely unlocked. All front panel

functions are available.

Lock mode 1 — All changes are locked from the front panel. Some functions

can be viewed.

Lock mode 2 — Basic functions are unlocked. Advanced features are locked

and can be viewed only.

Basic features consist of:

Making ties

Saving and recalling presets

Setting input audio gain and attenuation

Changing Lock modes

Advanced features consist of:

Creating I/O groups

Setting RGB delay

Setting video and audio output mutes

Setting audio output volume

Setting the rear panel remote port protocol and baud rate

N

The switcher is shipped from the factory in

Lock mode 2.

Selecting Lock mode 2 or toggling between mode 2 and mode 0

N

If the switcher is in

Lock mode 0 or mode 1, this procedure selects mode 2.

If the switcher in in

Lock mode 2, this procedure selects mode 0 (unlocks the

switcher).

Toggle the lock on and off by pressing and holding the Enter button, the RGBHV

button, and the Audio button for approximately 2 seconds (figure 3-64).

I / O

RGBHV AUDIO

ENTER

I / O

RGBHV AUDIO

ENTER

Press and

hold the Enter, RGBHV, and Audio

buttons simultaneously to turn on Lock mode 2 or to
toggle between mode 2 and mode 0.

2 seconds

The Enter, RGBHV, and
Audio buttons blink twice
to indicate the mode
change.
Release the buttons.

Figure 3-64 — Toggle front panel lock between mode 2 and mode 0
