Programmer’s Guide, cont’d
MVX Plus 128 VGA A Matrix Switcher • Programmer’s Guide
4-14
PRELIMINAR
Y
Command/response table for SIS commands (continued)
Command
ASCII command
(host to switcher)
Response
(switcher to host)
Additional
description
Resets
Reset global presets and names
E
ZG
}
Zpg
]
Clear all global presets and
their names.
Reset one global preset
EX1!
ZG
}
Zpg
X1!]
Clear global preset
X1!
.
Reset RGB delays
E
ZD
}
Zpd
]
Reset all RGB delays to 0.0
seconds.
Reset audio input levels
E
ZA
}
Zpa
]
Reset all audio input levels
(gain and attenuation) to 0 dB.
Rest audio output levels
E
ZV
}
Zpv
]
Reset all audio output
levels (volume) to 100% (no
attenuation).
Reset all mutes
E
ZZ
}
Zpz
]
Reset all video and audio
mutes.
Reset room map
E
ZR
}
Zpr
]
Clear all room presets.
Reset individual room
EX*
ZR
}
Zpr
X*]
Clear all presets for room
X*
.
Reset individual room preset
EX*
*
X1@
ZP
}
Zpp
X*
*
X1@]
Clear an individual room
preset and name.
Reset flash
E
ZFFF
}
Zpf
]
Reset flash memory (erase all
user-supplied files).
Reset whole switcher
E
ZXXX
}
Zpx
]
Clear all ties and presets,
reset all audio gains to 0 dB,
and reset volume to 100%.
Absolute reset
E
ZQQQ
}
Zpq
]
Similar to Reset whole
switcher
, plus clear the IP
address to 192.168.254.254
and subnet mask to
255.255.000.000.
View ties, gain, volume, mutes, presets, and DSVP
View RGBHV output tie
X#
&
X@]
Example:
15&
27
]
Input 27 RGBHV is tied to
output 15.
View video output tie
X#
%
X@]
Example:
7%
02
]
Input 2 video is tied to output 7.
View audio output tie
X#
$
X@]
Example:
3$
06
]
Input 6 audio is tied to output 3.
View input gain
X@
G
X$]
Example:
4G
-02
]
Gain for input 4 is -2 dB.
View output volume
X@
V
X&]
Example:
7V
55
]
Volume for output 7 is 55%.
View output mutes
E
VM
}
X1$
1
,
X1$
2
, ...
X1$]
Each
X1$
response is the
mute status of an output,
starting from output 1.
Example:
E
VM
}
02301000
]
Output 2 audio is muted,
output 3 video and audio are
muted, and output 5 video is
muted. All other outputs are
unmuted.
