Operation, cont’d

MVX Plus 128 VGA A Matrix Switcher • Operation

3-48

PRELIMINAR

Y

Configuration Worksheets

Rather than trying to remember the configuration for each preset, use worksheets

to record this information. Make copies of the blank worksheet on page 3-51 and

use one for each preset configuration. Cross out all unused or inactive inputs and

outputs. Use different colors for video and audio.

Worksheet example 1: System equipment

Figure 3-73 shows a worksheet for an MVX Plus in a fictional organization with

the system hardware annotated. Inputs 10 and 11 have no connection in this

organization, so they have been crossed out on the worksheet.

1

2

3

4

5

6

7

8

1

2

3

4

5

6

7

8

9

10

11

12

Preset #

Title:

Video:

Audio:

Fill in the preset number and use colors, or dashes, etc., to make connecting lines.
Indicate if the configuration is for video, audio, or both.

Classroom

#1 VCR

USP 405

Audio

CD

PC 2

RGB 202

PC 1

RGB 202

Weekly status mtg

3

Camera

#2

Camera/

mic - Main

podium

Main hall

FP #1

Main hall

FP #2

Podium

monitor

Sound

system

#1

Sound

system

#2

VCR

(VSC 500)

DA 6

Classroom

#2 VCR

USP 405

Laptop

RGB 202

Rack DVD

(USP 405)

VTG 300

Input sources

Output destinations

Figure 3-73 — Worksheet example 1: System equipment

Inputs include PCs, an audio CD player, cameras, and an Extron VTG 300. Output

devices include monitors, front and rear projectors, a stereo, and a VCR for

recording presentations.
The VTG 300 video test generator connected to input 12 enables a video test pattern

to be sent to one, several, or all output devices for problem isolation or adjustment

purposes. An audio test tape or CD could be used in a similar manner to check out

the audio components.
