5-11

MVX Plus 128 VGA A Matrix Switcher • Matrix Software

PRELIMINAR

Y

Mail Server IP Address field

The Mail Server IP Address field displays the IP address of the mail server that

handles the e-mail for the facility in which the MVX Plus VGA A switcher is

installed.
Valid IP addresses consist of four 1-, 2-, or 3-digit numeric octets separated by dots

(periods). Each field can be numbered from 000 through 255. Leading zeroes, up to

three digits total per field, are optional. Values of 256 and above are invalid.
Edit this field as follows:

1

.

Click in the mail server IP address field. The graphic cursor becomes a text

cursor.

2

.

Edit the IP address as desired.

3

.

Press the Tab key on the keyboard or click in another field to exit the mail

server IP address field.

4

.

Click the Take button to make the address change take affect.

Mail Server Domain Name field

The Mail Server Domain Name field displays the domain name that the

MVX Plus VGA A switcher uses to log on to the e-mail server. Standard domain

conventions (such as nnnnn@xxx.com) apply.

N

The following characters are invalid in a domain name:

{space} + ~ , = ‘ [ ] { } < > ’ “ ; : | \ and ?. The @ character is only
acceptable as the lead-in to the domain name (such as @folklore.net).

Edit this field as follows:

1

.

Click in the Mail Server Domain Name field. The graphic cursor becomes a

text cursor.

2

.

Edit the name as desired.

3

.

Press the Tab key on the keyboard or click in another field to exit the Mail

Server Domain Name field.

4

.

Click the Take button to make the name change take affect.
