GS-4012F/4024 User’s Guide
96 Chapter 10 Filtering
Action Select Discard source to drop frame from the source MAC address (specified in the
MAC field). The switch can still send frames to the MAC address.
Select Discard destination to drop frames to the destination MAC address (specified in
the MAC field). The switch can still receive frames originating from the MAC address.
Select Discard source and Discard destination to block traffic to/from the MAC
address specified in the MAC field.
MAC Type a MAC address in valid MAC address format, that is, six hexadecimal character
pairs.
VID Type the VLAN group identification number.
Add Click Add to save the new rule to the switch. It then displays in the summary table at the
bottom of the screen.
Cancel Click Cancel to reset the fields to your previous configuration.
Clear Click Clear to clear the fields to the factory defaults.
Index This field displays the index number of the rule. Click an index number to change the
settings.
Active This field displays Yes when the rule is activated and No when is it deactivated.
Name This field displays the descriptive name for this rule. This is for identification purpose
only.
MAC
Address
This field displays the source/destination MAC address with the VLAN identification
number to which the MAC address belongs.
Action This field displays the filter action.
Delete Check the rule(s) that you want to remove in the Delete column and then click the
Delete button.
Cancel Click Cancel to clear the selected checkbox(es) in the Delete column.
Table 19 FIltering (continued)
LABEL DESCRIPTION
