GS-4012F/4024 User’s Guide
Chapter 41 Command Examples 283
Figure 185 frame-type Command Example
41.8.10 spq
Syntax:
spq
Sets the interface to use Strict Priority Queuing.
An example is shown next.
• Enable ports one, three, four and five for configuration.
• Enable VLAN Trunking on the ports.
Figure 186 spq Command Example
41.8.11 wrr
Syntax:
wrr ...
where
An example is shown next.
• Enable port two and ports six to twelve for configuration.
• Enable Weighted Round Robin queuing on the ports.
• Set the queue weights from Q0 to Q7.
ras(config)# interface port-channel 1,3-5
ras(config-interface)# ingress-check
ras(config-interface)# frame-type tagged
ras(config)# interface port-channel 1,3-5
ras(config-interface)# spq
Enables WRR (Weighted Round Robin) queuing method on the switch.
...
Sets the interface to use WRR queuing. A weight value of one to eight is
given to each variable from
wt1 to wt8 .
