GS-4012F/4024 User’s Guide
158 Chapter 24 RIP
Figure 74 RIP
The following table describes the labels in this screen.
Table 52 RIP
LABEL DESCRIPTION
Active Select this check box to enable RIP on the switch.
Index This field displays the index number of an IP interface.
Network This field displays the IP interface configured on the switch.
Refer to the section on IP Setup for more information on configuring IP domains.
Direction Select the RIP direction from the drop-down list box. Choices are Outgoing, Incoming,
Both and None.
Version Select the RIP version from the drop-down list box. Choices are RIP-1, RIP-2B and RIP-
2M.
Apply Click Apply to save your changes back to the switch.
Cancel Click Cancel to begin configuring the fields again.
