GS-4012F/4024 User’s Guide

108

Chapter 14 Mirroring

Table 26 Mirroring

LABEL

DESCRIPTION

Active

Clear this check box to deactivate port mirroring on the switch.

Monitor

Port

The monitor port is the port you copy the traffic to in order to examine it in more detail

without interfering with the traffic flow on the original port(s). Select this port from this

drop-down list box.

Port

This field displays the port number.

Mirrored

Select this option to mirror the traffic on a port.

Direction

Specify the direction of the traffic to mirror. Choices are Egress (outgoing), Ingress

(incoming) and Both.

Apply

Click Apply to save the changes.

Cancel Click

Cancel to start configuring the screen again.
