GS-4012F/4024 User’s Guide
Product Specifications 309
Table 105 Physical and Environmental Specifications
LEDs Per switch: BPS, PWR, SYS, ALM
Per Gigabit Ethernet/mini-GBIC port: 100, 1000/LNK, ACT
Per mini-GBIC port: LNK, ACT
Per Management port: 10, 100
Dimension Standard 19” rack mountable
GS-4012F: 438 mm (W) x 225 mm (D) x 44.45 mm (H)
GS-4024: 438 mm (W) x 300 mm (D) x 44.45 mm (H)
Weight GS-4012F: 3.4 Kg
GS-4024: 4 Kg
Temperature Operating: 0º C ~ 45º C (32º F ~ 113º F)
Storage: -25º C ~ 70º C (13º F ~ 158º F)
Humidity 10 ~ 90% (non-condensing)
Power Supply Overload protection
AC model:100 - 240VAC 50/60Hz 1.5A max internal universal power supply
DC model: -48VDC--60VDC, 1.2A Max.
Fuse Rating T2A250VAC
Caution: For continued protection against risk of fire, replace only with the same type and fuse
rating.
Safety UL 60950-1
CSA 60950-1
EN 60950-1
IEC 60950-1
EMC FCC Part 15 (Class A)
CE EMC (Class A)
