GS-4012F/4024 User’s Guide
Chapter 8 VLAN 87
8.5.2 Configure a Static VLAN
To configure a static VLAN, click Static VLAN in the VLAN Status screen to display the
screen as shown next.
Table 14 VLAN: VLAN Status
LABEL DESCRIPTION
The Number of
VLAN
This is the number of VLANs configured on the switch.
Index This is the VLAN index number.
VID This is the VLAN identification number that was configured in the VLAN Setup
screen.
Port Number This column displays the ports that are participating in a VLAN. A tagged port is
marked as T, an untagged port is marked as U and ports not participating in a VLAN
are marked as “–“.
Elapsed Time This field shows how long it has been since a normal VLAN was registered or a static
VLAN was set up.
Status This field shows how this VLAN was added to the switch; dynamically using GVRP or
statically, that is, added as a permanent entry.
Poll Interval(s) The text box displays how often (in seconds) this screen refreshes. You may change
the refresh interval by typing a new number in the text box and then clicking Set
Interval.
Stop Click Stop to halt polling statistics.
Change Pages Click Previous Page or Next Page to show the previous/next screen if all status
information cannot be seen in one screen.
