GS-4012F/4024 User’s Guide
150 Chapter 22 Multicast
The following table describes the related labels in this screen.
22.5 MVR Group Configuration
All source ports and receiver ports belonging to a multicast group can receive multicast data
sent to this multicast group.
Configure MVR IP multicast group address(es) in the Group Configuration screen. Click
Group Configuration in the MVR screen.
Table 49 Multicast: Setting: MVR
LABEL DESCRIPTION
Active Select this check box to enable MVR to allow one single multicast VLAN to be
shared among different subscriber VLANs on the network.
Name Enter a descriptive name (up to 32 printable ASCII characters) for identification
purposes.
Multicast VLAN
ID
Enter the VLAN ID (1 to 4094) of the multicast VLAN.
Mode Specify the MVR mode on the switch. Choices are Dynamic and Compatible.
Select Dynamic to send IGMP reports to all MVR source ports in the multicast
VLAN.
Select Compatible to set the switch not to send IGMP reports.
Port This field displays the port number on the switch.
Source Port This field is applicable for Ethernet ports.
Select this option to set this port as the MVR source port that sends and receives
multicast traffic.
Receiver Port Select this option to set this port as a receiver port that only receives multicast
traffic.
None Select this option to set the port not to participate in MVR. No MVR multicast traffic
is sent or received on this port.
Tagging Select this checkbox if you want the port to tag the VLAN ID in all outgoing frames
transmitted.
Add Click Add to save the settings.
Cancel Click Cancel to discard all changes.
VLAN This field displays the multicast VLAN ID.
Active This field displays whether the multicast group is enabled or not.
Name This field displays the descriptive name for this setting.
Mode This field displays the MVR mode.
Source Port This field displays the source port number(s).
Receiver Port This field displays the receiver port number(s).
Delete To delete the group(s) and all the accompanying rules, select the group(s) that you
want to remove in the Delete column, then click the Delete button.
Cancel Click Cancel to clear the Delete check boxes.
