AWG610 Arbitrary Waveform Generator User Manual
C-1
Appendix C: Inspection and Cleaning
Inspect and clean the instrument as often as operating conditions require. The
collection of dirt can cause instrument overheating and breakdown. Dirt acts as
an insulating blanket, preventing efficient heat dissipation. Dirt also provides an
electrical conduction path
that can cause an instrument failure, especially under
high-humidity conditions.
CAUTION. To prevent damage avoid the use of chemical cleaning agents that
might damage the plastics used in this instrument. Use only deionized water
when cleaning the menu buttons or front-panel buttons. Use a ethyl alcohol
solution as a cleaner and rinse with deionized water.
Avoid the use of high pressure compressed air when cleaning dust from the
interior of this instrument. (High pressure air can cause ESD.) Instead, use low
pressure compressed air (about 9 psi).
Using Table C–1 as a guide, inspect the outside of the instrument for damage,
wear, and missing parts. You should thoroughly check instruments that appear to
have been dropped or otherwise abused to verify correct operation and perfor-
mance. Immediately repair defects that could cause personal injury or lead to
further damage to the instrument.
Table C-1: External inspection check list
Item Inspect for Repair action
Cabinet, front panel, and cover Cracks, scratches, deformations, damaged
hardware or gaskets
Replace defective module
FrontĆpanel knobs Missing, damaged, or loose knobs Repair or replace missing or defective knobs
Connectors Broken shells, cracked insulation, and
deformed contacts. Dirt in connectors
Replace defective modules; clear or wash out
dirt
Carrying handle and cabinet feet Correct operation Replace defective module
Accessories Missing items or parts of items, bent pins,
broken or frayed cables, and damaged
connectors
Replace damaged or missing items, frayed
cables, and defective modules
Inspection Ċ Exterior
