Getting Started
1-10
AWG610 Arbitrary Waveform Generator User Manual
Table 1-6: Power cord identification
Plug configuration
Normal usage
Option number
North America
Standard
Europe
A1
United Kingdom
A2
Australia
A3
North America
A4
Switzerland
A5
Push the PRINCIPAL POWER SWITCH (shown in Figure 1–1) on the rear
panel of the instrument. Power is now applied to the instrument standby
circuitry. Once the instrument is installed, leave the PRINCIPAL POWER
SWITCH on and use the ON/STBY switch, located on the front-panel, to turn
the instrument on and off.
Standby Power
