Getting Started
AWG610 Arbitrary Waveform Generator User Manual
1-9
Check that you have the proper electrical connections. The AWG610 Arbitrary
Waveform Generator generator operates within the following power supply
voltage and frequency ranges:
Line voltage range
100 - 240 V
Line frequency
48 - 63 Hz (100 - 240 V)
Maximum power
400 W
Connect the proper power cord from the rear panel power connector to the power
system.
NOTE. The AWG610 Arbitrary Waveform Generator is shipped with a 115 V
power cord. If the AWG610 Arbitrary Waveform Generator is to be used with
230 V power, the power cord must be replaced with one appropriate for the
power source used. See Table 1–6 for the available power cord types.
Check Voltage Settings
Connect Power Cord
