Command Descriptions
3-192
AWG610 Arbitrary Waveform Generator User Manual
Math Operators
Table 3–48 lists the programming language math operators that you can use as
part of waveform equation expressions.
Table 3-48: Math operators
Operators Description
Unary Arithmetic Operations
- Inverts the sign.
+ Does nothing.
Binary Operations
+ Addition
- Subtraction
* Multiplication
/ Division
^ Exponentiation
Binary Relational Operations
= If bothside values are equal, 1 results. Otherwise, 0 results.
<> If bothside values are not equal, 1 results. Otherwise, 0 results.
> If the left side value is larger than the right side value, 1 results.
Otherwise, 0 results.
>= If the left side value is larger than or equal to the right side value, 1
results. Otherwise, 0 results.
< If the left side value is smaller than the right side value, 1 results.
Otherwise, 0 results.
<= If the left side value is smaller than or equal to the right side value, 1
results. Otherwise, 0 results.
Binary Conditional Operator
and If bothside values are not 0, 1 results. Otherwise 0 results.
or If bothside values are 0, 0 results. Otherwise 1 results.
The operator priorities are as follows, starting with higher priority at the top of
the list. Operators on the same line have equal priority.
^
– (unary), + (unary)
*, /
=, <>, >, >=, <, <=
and, or
