Appendix B: Performance Verification
B-12
AWG610 Arbitrary Waveform Generator User Manual
Table B-3: Waveforms andsequences in performance check disk (cont.)
No. Usage Marker
setup
SETUP menu EDIT menu File name No. Usage Marker
setup
Offset Ampl Filter Clock Points Form
File name
10 TRIG.WFM 1000 1 MHz Through 1ĂV 0ĂV Trigger input
11 PT_EVENT.SEQ Event input
12 PT_STROB.SEQ Event input
13 S520.WFM
(PT_xxxxx.SEQ) 2
520 200 MHz Through 1ĂV 0ĂV Event input
14 S520H.WFM
(PT_xxxxx.SEQ) 2
520 200 MHz Through 1ĂV 0ĂV Event input
15 R520H.WFM
(PT_xxxxx.SEQ) 2
520 200 MHz Through 1ĂV 0ĂV Event input
16 T520H.WFM
(PT_xxxxx.SEQ) 2
520 200 MHz Through 1 V 0 V Event input
17 Q520H.WFM
(PT_xxxxx.SEQ) 2
520 200 MHz Through 1ĂV 0ĂV Event input
18 NULL520H.WFM
(PT_xxxxx.SEQ) 2
520 200 MHz Through 1ĂV 0ĂV Event input
1 The AMPx.SEQ represents AMP1.SEQ andAMP2.SEQ.
2 The PT_xxxxx.SEQ represents PT_EVENT.SEQ andPT_STROB.SEQ
