Reference

3-2

AWG610 Arbitrary Waveform Generator User Manual

Table 3–1 lists the four main menus in the AWG610 Arbitrary Waveform
Generator. Additional menu information can be found in the Reference section of
this manual beginning on page 3–3.

Table 3-1: AWG610 Arbitrary Waveform Generator main menus

button

Description

SETUP

Controls waveform output settings including trigger source and sample clock rate.

EDIT

Controls access to all functions for creating, editing, converting, importing and

exporting waveforms. Quick Editor functions are accessed through the Waveform

editor.
You can enterinto the Quick Editoronly from the waveform editor.

APPL

Creates signals for testing devices such as hard disks and networks, and also for

jittertesting and digital modulation.

UTILITY Controls instrument setup functions that are not directly related to editing or output.

Menus
