Site Configuration
5-23
User Parameters for Port 3
A description of the User parameters follows.
Link name
Contains the logical name of the link that the port is connected to. The link name is
automatically selected according to the Port Type parameters. For example, if the medium is
Radio, then ToolBox automatically selects RADIO1 as link name. If relevant, you can open
the drop down list and select another name.
Data Speed
If data speed is applicable to the port type parameters selected earlier, this parameter defines
the communication data speed of the selected media. The default is 9600. The IP Gateway
supports baud rates of up to 57,600.
Modulation
Defines the type of modulation, the data speed, and the communication standard. The various
available options for the three types of line interfaces are detailed in the following table.
Type of Modem
→ → → →
↓↓↓↓
Modulation
Full-
Duplex
2W/4W
Multi-Drop
Half-Duplex
Dial-Up Microwave
Full-Duplex
Microwave
Half-Duplex
FSK 300 bps,
CCITT V.21
√
- -
√
-
FSK 300 bps,
BELL 103
√
- -
√
-
DPSK 600 bps,
CCITT V.22
ASYNC 10 bits
√
-
√ √
-
DPSK 600 bps,
CCITT V.22
SYNC
√ √
-
√ √
DPSK 1200 bps,
CCITT V.22 &
BELL 212,
ASYNC 10 bits
√
-
√ √
-
DPSK 1200 bps,
CCITT V.22 &
BELL 212,
SYNC
√ √
-
√ √
QAM 2400 bps,
V.22 bis
ASYNC 10 bits
√
-
√ √
-
