Software Diagnostics Output
C-3
T_reset The amount of time a unit waits after having acknowledged repeated reset requests, before
sending its own reset frame.
T_dup The amount of time a unit, which has received frames with identical numbers, considers
them as duplicates instead of new transmissions.
T_hole The amount of time a unit, which has received frames with holes in the sequence numbers,
still expects to receiving the missing frames.
B_reset 1 means that the frame contains a reset bit.
B_ack 1 means that the frame contains a reset ACK bit.
## 23
Curr Since Last Diagnostic: Max # # Max #
Waiting Waiting Range Time Hole Resets
Buffers Buffers Holes Holes Len
Current Waiting Buffers Number of frames held in Waiting Queue.
Max Waiting Buffers Maximum number of frames in Waiting Queue.
# Range Holes The number of range “holes” found since the last diagnostic.
# Time Holes The number of time “holes” found since the last diagnostic.
Max Hole Len The maximum length of time “holes.”
# Resets The number of resets/rejects since the last diagnostic.
HEAP DEVICE = HP_F_TX, HP_F_RX, HP_UF_A, HP_UF_U
HP_F_TX, HP_F_RX MDLC Formatted
HP_UF_A MDLC adapter (unformatted)
HP_UF_U USER Port
