SW Diagnostics & Loggers
5-173
REQMNG Requirements Manager device
The meaningful levels are 0, 1. Diagnostic levels of 2, 3, 4 are for internal use only.
Example of Level 0 Diagnostics:
Oct 31 09:45:36 Site: 10000 Link: Rslink1 Device: REQMNG Level: 0
max clients :4
max channels :18
max buffers :10
comm buffer length :8256
clients offset :84
channels offset :324
buffers offset :936
read list offset :900
next client :20
next channel :10
n read channels :5
cur buf :0
gateway id :1
gateway status :1H
client error :0H
mng thread channel :0
tx global :901b6H
rx global :8b192H
mng global :8616eH
site id :0
startup mode :0
left :0
Interesting fields:
Static Data
max clients :4
max channels :18 (Allocated channels + 2)
max buffers :10
gateway id :1
startup mode :0 - Stand-alone
:1 - Redundant 1
:2 - Redundant 2
Dynamic Data
gateway status :1H - Primary mode
:5H - Secondary mode
