Network Configuration
5-71
Dialog box parameters
Site ID
Enter the Site ID of the unit to which the network configuration is to be downloaded.
Link ID
Enter the Link ID of the unit to which the network configuration is to be downloaded.
OK
Click this button to start the download process. While the Network Configuration tool is
communicating with the RTU, the icon at the top right hand corner of the Network
Configuration window will be animated.
Font
The Font command (Network Configuration, Tools menu) is used to change the current
settings for font name, style, size, etc.
View Menu
The View menu enables you to view or hide various screens from the utility window. Pull
down the menu and click on an entry to toggle the viewing. The following views are available
to the user.
Toolbar
The Toolbar displays the icons described under Icons.
Status bar
The Status bar displays the status messages at the bottom of the Network Configuration
window.
Download window
The Download window displays a window with the progress and status of the download at the
bottom of the Network Configuration window. This window can be dragged to a different area
of the screen and can be closed by clicking on the X in the upper left-hand corner of the
window. This window is read-only.
Window Menu
The Window menu enables the user to arrange the various screens within the Network
Configuration window. The screens can also be moved, resized or closed as standard
Windows. In addition to the commands below, the Window menu lists the currently open
windows. The checked name is the active screen. By clicking on another filename, the user
can change the active screen.
