Communication Setup
5-138
Apply
The Apply button saves changes made to the Communication Setup. A message will
appear reminding you to close any ToolBox utilities and Stop the Communication Driver
in order for the changes to take place. Press OK to close the window.
More
If you press the More button, the Communication Setup window will expand as follows:
Dialog box parameters
Less
If you press the Less button, the Communication Setup window will shrink back to its
original size.
Number of MASTER logical channels
Specify the number of logical channels in the MDLC protocol capable of initiating
communication via a session oriented channel.
Number of retries to declare TX FAIL
Specify the number of retries at session oriented logical channel level after which the
Transport Layer declares that transmission to destination site has failed.
Interval between Tx retries
Specify the interval of time that should elapse between two retries at Source/Destination
level.
Formatted buffer size
Specify the size of the formatted buffer that serves as asynchronous port.
Restore Default
If you press the Restore Default button, the default values for the four parameters on the
right side of the Communication Setup window will return to their original values.
