SW Diagnostics & Loggers
5-176
STBLA Sites Table Device
Tue Dec 21 09:02:44 1999 SITE: Local DEVICE: STBLA LEVEL: 0
Version of Site-Table Downloader : 400
The Target Unit (1-VRM-100, 2-Gateway): 4
Size of Downloaded Site Table
: 101
Size of Learning Site Table : 100
Tue Dec 21 09:03:19 1999 SITE: Local DEVICE: STBLA LEVEL: 1
Learning Site-Table:
Site-ID Link-ID
======== =======
0 0
0 0
0 0
0 0
Tue Dec 21 09:03:25 1999 SITE: Local DEVICE: STBLA LEVEL: 2
Downloaded Site-Table:
Site-ID Link-ID Retries Timeout
======== ======= ======= =======
65533 1 30 254 300 254 300
100 1 30 51 300 51 300
101 1 30 51 300 51 300
102 1 30 51 300 51 300
103 1 30 51 300 51 300
104 1 30 51 300 51 300
105 1 30 51 300 51 300
106 1 30 51 300 51 300
107 1 30 51 300 51 300
108 1 30 51 300 51 300
109 1 30 51 300 51 300
Start
The Start command begins retrieval of error logger or diagnostics information from the IP
Gateway. The information is displayed in the appropriate logger window. When the ToolBox
is communicating with the IP Gateway, the Start icon and command will be dimmed. While
the SW Diagnostics & Loggers utility is communicating with the IP Gateway, the
icon at the top right hand corner of the SW Diagnostics & Loggers window will be animated.
Device List
(SW Diagnostics only) A basic device list is available when you open the SW Diagnostics
tool. The Device List command updates the device list with all the devices actually residing in
the IP Gateway.
