SW Diagnostics & Loggers
5-171
Link ID Link Adapter Physical Layer
Rslink 12 RTU RTU RTU
Rslink 13 RTU=L RTU=A RTU=P
Rslink 14 RTU>L RTU>A RTU>P
Rslink 15 RTU?L RTU?A RTU?P
Rslink 16 RTU@L RTU@A RTU@P
Rslink 17-Rslink 19 RTUAL-RTUCL RTUAA-RTUCA RTUAP-RTUCP
Rslink 20-Rslink 99 S020L-S099L S020A-S099A S020P-S099P
Rslink 100-Rslink 200 S100L-S200L S100A-S200A S100P-S200P
Radio 1-Radio 9 RAD1L-RAD9L RAD1A-RAD9A RAD1P-RAD9P
Radio 10-Radio 99 R010L-R099L R010A-R099A R010P-R099P
Radio 100-Radio 200 R100L-R200L R100A-R200A R100P-R200P
Computer 1-Computer 9 COM1L-COM9L COM1A-COM9A COM1P-COM9P
Terminal Server 1-
Terminal Server 32 TS1L-TS32L TS1A-TS32A TS1P-TS32P
Reading Diagnostics Information
The structure of the statistical data is described below for each device name.
COMxA (Adapter device of Computer X)
Jun 30 14:49:10 Site: LOCAL Device: COM1A Level: 11
# of Transmitted Frames : 6
# of Re-transmitted Frames : 0
# of Received Frames : 6
# of Received Frames (With Error): 0
The # of Received Frames includes only correct frames (including acknowledgment frames).
The # of Re-transmitted Frames represents only frames rejected by the physical layer (do not
use this number; use the # of Re-transmitted Frames in the Link device).
RADxL (Link device of Radio X)
Jun 30 14:50:10 Site: LOCAL Device: RAD1L Level: 11
# of Transmitted Frames : 0
# of Re-transmitted Frames : 0
# of Received Frames : 0
# of Received Frames (With Error): 0
