SW Diagnostics & Loggers
5-174
Example of Level 1 Diagnostics:
Oct 31
09:45:36
Site: 10000
Link: Rslink1
Device: REQMNG Level:
1
name
free
id
tx
burst
error
myclnt
0
1
2
2
0
another
0
2
3
3
0
1
255
255
255
0
1
255
255
255
0
Interesting fields:
The name column indicates the names of the connected clients, (if a row starts with 1, the first
- name field is empty).
LNKHNDL
Tue Dec 21 09:00:50 1999
SITE: Local
DEVICE: LNKHNDL
LEVEL: 1
Site #:
100
Site Up
Time :
2
Site Discover Time :
3
Site Down Time :
0
Site Mirror
Time :
4
Primary
Link
51
is Up
1
0
Secondary Link
51
is Up
1
0
Site #:
101
Site Up
Time :
3
Site Discover Time :
6
Site Down Time :
0
Site Mirror
Time :
7
Primary
Link
51
is Up
1
0
Secondary Link
51
is Up
1
0
Site #:
102
Site Up
Time :
4
Site Discover Time :
9
Site Down Time :
0
Site Mirror
Time :
9
Primary
Link
51
is Up
1
0
Secondary Link
51
is Up
1
0
Site #:
167
Site Up
Time :
69
Site Discover Time :
165
Site Down Time :
0
Site Mirror
Time :
166
Primary
Link
51
is Up
1
0
Secondary Link
51
is Up
1
0
HELTHCH Health Check Device
Tue Dec 21 09:01:37 1999
SITE: Local
DEVICE: HELTHCH
LEVEL: 0
Health Check Diagnostics
------------------------
Actual number of RTUs:
100
Maximum RTUs:
500
Time to wait in ping task:
1000
mili seconds
Time to wait in pong task:
1000
mili seconds
Time to wait in dead task:
1000
mili seconds
Time to give up ping:
900
seconds
Number of pings until fail:
2
pointer to pingHndl:
fa32H
pointer to deadHndl:
fa58H
pointer to pongHndl:
fa44H
pointer to rtuList:
f240H
pointer to notify function:
206f698H
parameter to notify function:
0H
TMUX key:
1b96392H
FRAM_SEQ key:
1d51ca6H
System maximum ping trials
1
