2 mounting order, Mounting order – FUJITSU PRIMERGY MX130 S2 User Manual
Page 82
82
Upgrade and Maintenance Manual
MX130
S2
HDDs and accessible drives
7.2
Mounting order
Maximum configuration: 4 x 3.5-inch HDD + slimline ODD
Figure 21: Slimline ODD mounting order with 4 x 3.5-inch HDD
Figure 22: Slimline ODD mounting order with 3 x 3.5inch HDD or 2 x 3.5inch HDD and RDX
Figure 23: HH ODD or RDX mounting order with 3 x 3.5-inch HDD
HDD1
HDD2
HDD3
HDD4
Slimline ODD
Slimline ODD
HDD3 / RDX
HDD1
HDD2
HH ODD / RDX
HDD3
HDD1
HDD2
