Page 251
MX130 S2
Upgrade and Maintenance Manual
251
Appendix
15.3.1.3 I/O panel connectors
Figure 162: Connector panel on the rear side
1 PS2 connector (for mouse)
2 Serial connector (COM1)
3 Standard LAN connector
4 Audio connectors (optional for specific markets)
5 6 USB connectors
6 Video connector (DVI-I)
7 PS2 connector (for keyboard)
1
0
/
3
4
2
3
5
