112

Upgrade and Maintenance Manual

MX130

S2

HDDs and accessible drives

7.11.4 Concluding steps

Perform the following procedures to complete the task:

Ê

Follow all procedures described in section

"Closing the server" on page 54

.

7.12 Removing 5.25-inch dummy cover

7.12.1 Required tools

●

Preliminary and concluding steps: tool-less

●

Removing the dummy cover: tool-less

7.12.2 Preliminary steps

Before removing the dummy cover, perform the following steps:

Ê

Follow all procedures described in section

"Opening the server" on page 48

.

Upgrade and Repair Units (URU)

Average task duration: 5 minutes
