Page 172: Concluding steps
172
Upgrade and Maintenance Manual
MX130
S2
Expansion cards
9.2.4.4
Removing an eSATA cable
Figure 106: Removing an eSATA cable
Ê
Fold up the locking handle on the slot bracket clamp.
Ê
Carefully remove the eSATA cable from its slot.
9.2.4.5
Concluding steps
Perform the following procedures to complete the task:
Ê
Install a PCI slot bracket as described in section
Ê
Follow all procedures described in section
"Closing the server" on page 54
.
