MX130 S2 Upgrade and Maintenance Manual 229
Front panel and front USB
13.2 Replacing the front USB board
13.2.1 Required tools
●
Preliminary and concluding steps: tool-less
●
Replacing the front panel module:
– Phillips PH2 / (+) No. 2 screw driver
13.2.2 Preliminary steps
Ê
Follow all procedures described in section "Opening the server" on page 48 .
Ê
Open the front cage as described in section "Opening the front cage" on
page 52 .
Field Replaceable Units (FRU)
Average task duration: 15 minutes
