MX130 S2 Upgrade and Maintenance Manual 127
HDDs and accessible drives
Figure 64: Removing the 5.25-inch ODD/HDD bracket with the slimline ODD
Ê
Push the green handle backward (1) and pull the 5.25-inch ODD/HDD
bracket out of its bay (2).
V
CAUTION!
Always replace dummy modules into unused drive bays to comply with
applicable EMC regulations and satisfy cooling requirements.
/
