Upgrade and Maintenance Manual

MX130

Expansion cards

9.2.3

Installing eSATA cable

9.2.3.1

Required tools

●

Preliminary and concluding steps: tool-less

●

Installing expansion cards: tool-less

9.2.3.2

Preliminary steps

Before installing an expansion cable, perform the following steps:

Follow all procedures described in section

Remove a PCI slot bracket as described in section

9.2.3.3

Installing an eSATA cable (optional for specific markets)

Remove the eSATA cable from its protective packaging.

For further instructions regarding controller settings, please refer to
the "Description - BIOS Manual D3090 / D3091".

Upgrade and Repair Units (URU)

Average hardware task duration: 5 minutes
