3 network adapter d2745, Network adapter d2745 – FUJITSU PRIMERGY MX130 S2 User Manual
Page 176
176
Upgrade and Maintenance Manual
MX130
S2
Expansion cards
9.3.1.3
Network adapter D2745
Figure 110: Network adapter D2745 - Mounting the slot bracket (A)
Ê
Hinge the slot bracket to the plug shell as shown (1).
Ê
Fold the slot bracket towards the controller until the threaded mounting tab
is aligned with the screw hole on the controller (2).
