Appendix G: Defining the MapInfo Codespace
Defining the MapInfo Codespace
MapXtreme v7.1 567 Developer Guide
imagesize pixel A non-linear unit of image dimension.
Example: mapinfo:imagesize pixel
type A data type.
boolean Example: mapinfo:type boolean
byte Example: mapinfo:type byte
date Example: mapinfo:type date
datetime Example: mapinfo:type datetime
time Example: mapinfo:type time
decimal [ | ( n n ) | ] n.m
n is the
total digits
and
m is the
number of
digits
reserved
for the
right of
decimal
point,
m<=n optional min
optional max
optional precision
Examples:
mapinfo:type decimal (100 -- all d>100
mapinfo:type decimal 100) -- all d<100
mapinfo:type decimal [200 300] -- all
200<=d<=300
mapinfo:type decimal 10.7 -- all
decimals with no more than 10 digits
with 7 digits reserved for right of
decimal point, thus max of 3 digits to
left of decimal point.
mapinfo:type decimal [200 300] 10.7 --
combination of previous two examples.
double [ | ( n n ) | ] Example: mapinfo:type double (0 150)
float [ | ( n n ) | ] Example: mapinfo:type float 30.25]
int [ | ( n n ) | ] Example: mapinfo:type int [0 180]
short [ | ( n n ) | ] Example: mapinfo:type short
string n Optional max length n.
Example: mapinfo:type string 256
char Example: mapinfo:type char
MapInfo Codespace Definition (continued)
Category Position 1
Position
2
Position
3
Position
4 Explanation and Example
