Or %r,%r’ or %r,imm4 – Epson S1C63000 User Manual
Page 118
112
EPSON
S1C63000 CORE CPU MANUAL
CHAPTER 4: INSTRUCTION SET
OR %r,%r’
OR %r,imm4
Logical OR of r’ reg. and r reg.
1 cycle
Function:
r
←
r
∨
r’
Performs a logical OR operation of the content of the r’ register (A or B) and the content of the r
register (A or B), and stores the result in the r register.
Code:
Mnemonic
MSB
LSB
OR %A,%A
1
1
0
1
1
0
1
1
1
0
0
0
X
1B70H, (1B71H)
OR %A,%B
1
1
0
1
1
0
1
1
1
0
0
1
X
1B72H, (1B73H)
OR %B,%A
1
1
0
1
1
0
1
1
1
0
1
0
X
1B74H, (1B75H)
OR %B,%B
1
1
0
1
1
0
1
1
1
0
1
1
X
1B76H, (1B77H)
Flags:
E
I
C
Z
↓
–
–
↕
Mode:
Src: Register direct
Dst: Register direct
Extended addressing: Invalid
Logical OR of immediate data imm4 and r reg.
1 cycle
Function:
r
←
r
∨
imm4
Performs a logical OR operation of the 4-bit immediate data imm4 and the content of the r
register (A or B), and stores the result in the r register.
Code:
Mnemonic
MSB
LSB
OR %A,imm4
1
1
0
1
1
0
1
0
0 i3 i2 i1 i0
1B40H–1B4FH
OR %B,imm4
1
1
0
1
1
0
1
0
1 i3 i2 i1 i0
1B50H–1B5FH
Flags:
E
I
C
Z
↓
–
–
↕
Mode:
Src: Immediate data
Dst: Register direct
Extended addressing: Invalid
